Hearthstone Mansfield Wood Stove

RELAXED GOOD LOOKS THAT DELIVER LASTING WHOLE-HOUSE WARMTH
A true workhorse, the Mansfield is a top-seller among hearth professionals. Providing up to 14 hours of sustained heat on a single load of wood, the Mansfield delivers confortable warmth throughout your home.

Heats up to: 2,500 sq.ft.
Firebox Capacity: 3.2 cu.ft.
Size: Up to 80,000 BTUs
EPA Certified: 2.9 gph
Efficiency: 77% LHV
Burn time: Up to 12 hours
HeatLife: Up to 16 hours
Maximum Log Length: 21 in.

Description

Specifications
Heats up to 2500 sq.ft.
Burn Time Up to 10 hours
Heat Life up to 14 hours
BTU 80000
EPA Rating (grams/hr) 2.8
Efficiency (HHV CSA B415.1) 67%
Configuration Freestanding
Width 27 in.
Height (includes flue collar) 31 1/2 in.
Depth 24 in.
Maximum Log Length 21 in.
Firebox Capacity 3.2 cu. ft.
Flue Diameter 6 in.
Flue Exit Top
Ash Pan Yes
Blower Optional
Actual Weight (lbs.) 555
Alcove Certified Yes
Mobile Home Certified Yes
Clearances (With double-wall pipe & rear heat shield)
Side 18 in.
Rear 8 in.
Corner 14 in.
Hearth Pad
Minimum Size (US) 34 in. W x 40 in. D
Minimum Size (Canada) 40 1/2 in. W x 48 in. D
Minimum R-value Ember Protection
Clearances – With single wall pipe & no rear heat shield
Side 18 in.
Rear 19 in.
Corner 14 in.
